Vena® Flexip
Oily, fatty products and glycols resistant hose
The inner layer for this hose is made of fluoroelastomers and PTFE particles, which makes it have a good resistance to both acidic and basic CIP cleaning solutions.
Applications
This hose is specially recommended for the transport of liquid or semi-liquid fluids in the food, cosmetic, chemical and pharmaceutical industries. It has good resistance specially in fatty products or oily foods and glycols, as well as alcoholic beverages. Shapes such as elbows and curvatures can also be manufactured to adapt them to any installation.
Features
White and smooth
White and smooth
-20ºC(+4ºF) to 175ºC (347ºF) it may reach up to 200ºC (372ºF)
The standard manufacturing length is 4 meters long (13.12 ft) but in specific diameters a length of 6 meters (19.69 ft) can be manufactured.
0.91 bar(13.23 psi)
Quality
− US FDA Standard 21 CFR 177.2600.
− USP Class VI <88> in vivo test, 121ºC.
ResAp 2004 (5), according to Reg 1935/2004/EEC, and Reg10/2011/EEC with simulants A (10% of ethanol) and simulant D2 (olive oil).
Customization
Silicone label
QR Marking
Special marking
Molded clamps
Standard fittings
Clamps fittings with an inner cover of PFA (under request)
316L Stainless steel fittings on each with a roughness value of less than 0.8µm (or 0.5 µm on request) crimped with SZR system (no retention area).
Elbows and special shapes under request
