Foodpharma

Vena® Flexpure

PTFE flexible hose

The inner layer for this hose is made of PTFE, which makes it have a good resistance to any agressive chemical.

Applications

Due the ultra-flexible smoothbore construction, it is ideal for powder, liquid and semiliquid processing in applications where a high hygienic design and good mechanical performance are required.

Download data sheet

Features

outer_layer
Outer Layer

White and smooth

inner_layer
Inner Layer

White and smooth

temperature
Temperature

-50ºC(+58ºF) to +200ºC(392ºF)

manufacturing_length
Manufacturing Length

Standard length is 4 (13.12ft) meters long but in specific diameters a length of 6 meters (19.69 ft) can be manufactured.

Quality

The inner PTFE is in compliance with US FDA Standard 21 CFR 177.550

The inner PTFE is in compliance with USP Class VI <88> in vivo test, 121ºC

The inner PTFE is in compliance with European Regulation (EU) 10/2011

The outer white silicone is in accordance with: US FDA Standard 21 CFR 177.260

This hose is in accordance with the RoHS Directive 2002/95/EC and its subsequent amendments including the RoHS2 Directive 2011/65/EU and RoHS3 Directive 2015/863

Customization

check
Outer layer
  • X: Black conductive silicone

check
Traceability
  • QR Marking

  • Special Marking

check
Assemblies
  • 316L Stainless steel SZR crimp fittings
