Foodpharma

Vena® Vitosil

Chemical resistant silicone hose with FKM inner layer

Flexible silicone hose with an FKM inner layer suitable for aggressive fluids.

Applications

Due to the inner FKM layer it’s especially recommended to convey aggressive fluids that are not compatible with silicone, like acids or oils. This hose is able to transport liquid or semi-liquid foodstuffs at high temperatures by impulsion or suction, since their design can resist pressure or vacuum.

Download data sheet

Features

outer_layer
Outer Layer

VMQ Silicone, smooth and translucent.

reinforcement
Reinforcement

Stainless steel wire spring and polyester fabric reinforcement.

inner_layer
Inner Layer

FKM, smooth and black.

temperature
Temperature

-30ºC / +180ºC (-75F / 356ºF)

manufacturing_length
Manufacturing Length

4 meters (13.12 ft.). 6m in standard diameters.

vacuum_pressure
Vacuum Pressure

0.91 Bar (13.23 psi)

Quality

FDA-CFR 21, item 177.2600.

ResAp 2004 (5), according to Reg. 1935/2004/EEC, and Reg. 10/2011/EEC.

Customization

check
Outer layer
  • Telcra: Innovative insulating material.

  • X: Black conductive silicone.

check
Reinforcement
  • AC: Copper wire spiral to improve static electricity discharge.

  • Plastic wire (Vena Sil 650V Plastic).

check
Traceability
  • QR Marking

  • Special marking

check
Assemblies
  • 316L Stainless steel SZR crimp fittings
