Venaflon® HR

Chemical resistant rubber hose with USP VI PFA inner layer

EPDM rubber hose with an inner layer of PFA, compatible with highly aggressive chemicals.

Applications

It is specially recommended for the transport of liquid or semi-liquid stuffs by impulsion or suction, since its design can resist either pressure or vacuum. Venaflon HR is an excellent solution to withstand dynamic stress during the transfer of high purity fluids. It’s suitable for use in filling machines and also for long lines of product transfer between tanks.

Download data sheet

Features

outer_layer
Outer Layer

EPDM rubber, rough and blue.

reinforcement
Reinforcement

Stainless steel wire spring and polyester fabric reinforcement.

inner_layer
Inner Layer

PFA fluoropolymer, smooth and white.

temperature
Temperature

-40ºC / +150C (-40ºF / 302ºF)

manufacturing_length
Manufacturing Length

20m (65.62 ft). Can be cutted under request.

vacuum_pressure
Vacuum Pressure

0.9 Bar (13.05 psi).

Quality

Customization

check
Traceability
  • QR Marking

  • Special marking

check
Assemblies
  • 316L Stainless steel SZR crimp fittings

  • Molded clamps
