Industrial

Vena ® HT/HTD

Silicone ducting for air conduction and fumes extraction at high temperatures

Silicone ducting for conveying air or gaseous fluids at high temperatures with high flexibility and high resistance to ageing.

Applications

Recommended for the extraction of hot air from ceramic kilns.

Suitable for its use in applications when there's a need for transporting hot air:

  • A heating airplane or helicopter cockpits
  • Ventilation and climate control onboard ships
  • Protection of electricity cables
Download data sheet

Features

outer_layer
Outer Layer

Silicone VMQ, corrugated and red.

reinforcement
Reinforcement

One layer (HT) or two layers (HTD) of fiberglass and steel wire spiral.

inner_layer
Inner Layer

Silicone VMQ, corrugated and red.

temperature
Temperature

-55°C to +260°C. (-67°F/ +500°F)

manufacturing_length
Manufacturing Length

4m (13’). 6m upon request (19’8’’).

Quality

The material is in compliance with the RoHS Directive 2002/95/EC and its subsequent amendments including the RoHS2 Directive 2011/65/EU and RoHS3 Directive 2015/863.

Customization

check
Connections
  • Smooth cuff ends for a better connection.

check
Diameters
  • Between 13 and 300mm (1/2" to 12")
