Industrial

Vena ® MT/MTD

Industrial neoprene ducting for air conduction and fumes extraction

Industrial neoprene ducting for conveying air or gaseous fluids at medium temperatures with high flexibility and high resistance to ageing

Applications

This product is recommended for:

  • Air ventilation
  • Extraction of engine fumes
  • Cooling of electronic units
  • Welding gas aspiration
Download data sheet

Features

outer_layer
Outer Layer

Neoprene, corrugated and black.

reinforcement
Reinforcement

One layer (MT) or two layers (MTD) of fiberglass and steel wire spiral.

inner_layer
Inner Layer

Neoprene, corrugated and black.

temperature
Temperature

-55°C/+125°C (-67°F/+257°F)

manufacturing_length
Manufacturing Length

4m (13’). 6m upon request (19’8’’)

Quality

The material is in compliance with the RoHS Directive 2002/95/EC and its subsequent amendments including the RoHS2 Directive 2011/65/EU and RoHS3 Directive 2015/863.

Customization

check
Material
  • ECO material: Special flame retardant neoprene classified as HL3 according to EN-45545-2 standard

check
Connections
  • Smooth cuff ends for a better connection.

check
Diameters
  • Between 13 and 300mm (1/2" to 12")
