Industrial

Vena ®MTD ECO

Fire and Fumes certified neoprene ducting for air conduction and fumes extraction

HL3 R22 & R23 (EN-45545-2) and V0 (UL-94) classified neoprene ducting for conveying air or gaseous fluids at medium temperatures with high flexibility and high resistance to ageing

Applications

  • Air ventilation
  • Extraction of engine fumes
  • Cooling of electronic units
  • Welding gas aspiration.
    Especially recommended for air ventilation in the railway industry where the fire & fumes classification is required.
Download data sheet

Features

outer_layer
Outer Layer

Neoprene, corrugated and pink.

reinforcement
Reinforcement

Two layer of fiberglass and steel wire spiral.

inner_layer
Inner Layer

Neoprene, corrugated and pink.

temperature
Temperature

-55°C/+125°C (-67°F /+257 °F)

manufacturing_length
Manufacturing Length

4m (13’). 6m upon request (19’8’’)

Quality

HL3 R22 & R23 (EN-45545-2) and V0 (UL-94)

The material is in compliance with the RoHS Directive 2002/95/EC and its subsequent amendments including the RoHS2 Directive 2011/65/EU and RoHS3 Directive 2015/863.

Customization

check
Connections
  • Smooth cuff ends for a better connection.

check
Diameters
  • Between 13 and 300mm (1/2" to 12")
